Le standard pharmaceutique ASME est produit selon la norme ASME BPE 2014 en matière 316L
Le Ra extérieur de 0,8 µm et un Ra intérieur de 0,5 µm
Sur demande : Ra 0,38 µm électropoli
TUBES INOX 316L ASME BPE
| DN | Ep. | Poids | Nature |
| 1/2" | 1.65 | 0.400 | 316L |
| 3/4" | 1.65 | 0.719 | 316L |
| 1" | 1.65 | 0.981 | 316L |
| 1"1/2 | 1.65 | 1.506 | 316L |
| 2" | 1.65 | 2.031 | 316L |
| 2"1/2 | 1.65 | 2.556 | 316L |
| 3" | 1.65 | 3.076 | 316L |
| 4" | 2.11 | 5.256 | 316L |
REDUCTIONS CONCENTRIQUES à SOUDER ASME BPE
| DN | EP.1 | EP.2 | A | Nature |
| 3/4"-1/2" | 1.65 | 1.65 | 101.6 | 316L |
| 1"-1/2" | 1.65 | 1.65 | 114.3 | 316L |
| 1"-3/4" | 1.65 | 1.65 | 101.6 | 316L |
| 1"1/2-3/4" | 1.65 | 1.65 | 127 | 316L |
| 1"1/2-1" | 1.65 | 1.65 | 127 | 316L |
| 2"/1" | 1.65 | 1.65 | 184.2 | 316L |
| 2"-1"1/2 | 1.65 | 1.65 | 133.4 | 316L |
| 2"1/2-1"1/2 | 1.65 | 1.65 | 184.2 | 316L |
| 2"1/2-2" | 1.65 | 1.65 | 139.7 | 316L |
| 3"-1"1/2 | 1.65 | 1.65 | 235 | 316L |
| 3"-2" | 1.65 | 1.65 | 190.5 | 316L |
| 3"-2"1/2 | 1.65 | 1.65 | 139.7 | 316L |
| 4"-2" | 2.11 | 1.65 | 298.4 | 316L |
| 4"-2"1/2 | 2.11 | 1.65 | 244.7 | 316L |
| 4"-3" | 2.11 | 1.65 | 196.9 | 316L |
REDUCTIONS EXCENTRIQUES à SOUDER ASME BPE
| DN | EP.1 | EP.2 | A | Nature |
| 3/4"-1/2" | 1.65 | 1.65 | 101.6 | 316L |
| 1"-1/2" | 1.65 | 1.65 | 114.3 | 316L |
| 1"-3/4" | 1.65 | 1.65 | 101.6 | 316L |
| 1"1/2-3/4" | 1.65 | 1.65 | 127 | 316L |
| 1"1/2-1" | 1.65 | 1.65 | 127 | 316L |
| 2"/1" | 1.65 | 1.65 | 184.2 | 316L |
| 2"-1"1/2 | 1.65 | 1.65 | 133.4 | 316L |
| 2"1/2-1"1/2 | 1.65 | 1.65 | 184.2 | 316L |
| 2"1/2-2" | 1.65 | 1.65 | 139.7 | 316L |
| 3"-1"1/2 | 1.65 | 1.65 | 235 | 316L |
| 3"-2" | 1.65 | 1.65 | 190.5 | 316L |
| 3"-2"1/2 | 1.65 | 1.65 | 139.7 | 316L |
| 4"-2" | 2.11 | 1.65 | 298.4 | 316L |
| 4"-2"1/2 | 2.11 | 1.65 | 244.7 | 316L |
| 4"-3" | 2.11 | 1.65 | 196.9 | 316L |
COUDES à SOUDER à 90° ASME BPE
| DN | EP | A | B | R | Nature |
| 1/2" | 1.65 | 76.2 | 50.8 | 25.4 | 316L |
| 3/4" | 1.65 | 76.2 | 50.8 | 25.4 | 316L |
| 1" | 1.65 | 76.2 | 38.1 | 38.1 | 316L |
| 1"1/2 | 1.65 | 95.3 | 38.1 | 57.2 | 316L |
| 2" | 1.65 | 120.7 | 44.5 | 76.2 | 316L |
| 2"1/2 | 1.65 | 139.7 | 44.5 | 95.3 | 316L |
| 3" | 1.65 | 158.8 | 44.5 | 114.3 | 316L |
| 4" | 2.11 | 203.2 | 50.8 | 152.4 | 316L |
COUDES à SOUDER à 45° ASME BPE
| DN | EP | A | B | R | Nature |
| 1/2" | 1.65 | 57.2 | 46.7 | 25.4 | 316L |
| 3/4" | 1.65 | 57.2 | 46.7 | 25.4 | 316L |
| 1" | 1.65 | 57.2 | 41.4 | 38.1 | 316L |
| 1"1/2 | 1.65 | 63.5 | 39.8 | 57.2 | 316L |
| 2" | 1.65 | 76.2 | 44.6 | 76.2 | 316L |
| 2"1/2 | 1.65 | 85.7 | 47 | 95.3 | 316L |
| 3" | 1.65 | 92.1 | 44.8 | 114.3 | 316L |
| 4" | 2.11 | 114 | 51.2 | 152.4 | 316L |
TES à SOUDER ASME BPE
| DN | e | A | Nature |
| 1/2" | 1.65 | 47.6 | 316L |
| 3/4" | 1.65 | 50.8 | 316L |
| 1" | 1.65 | 54 | 316L |
| 1"1/2 | 1.65 | 60.3 | 316L |
| 2" | 1.65 | 73 | 316L |
| 2"1/2 | 1.65 | 79.4 | 316L |
| 3" | 1.65 | 85.7 | 316L |
| 4" | 2.11 | 104.8 | 316L |
TES REDUITS à SOUDER ASME BPE
| DN | EP.1 | EP.2 | A | B | Nature |
| 3/4"-1/2" | 1.65 | 1.65 | 50.8 | 316L | |
| 1"-1/2" | 1.65 | 1.65 | 54 | 316L | |
| 1"-3/4" | 1.65 | 1.65 | 54 | 316L | |
| 1"1/2-3/4" | 1.65 | 1.65 | 60.3 | 316L | |
| 1"1/2-1" | 1.65 | 1.65 | 60.3 | 316L | |
| 2"/1" | 1.65 | 1.65 | 73 | 316L | |
| 2"-1"1/2 | 1.65 | 1.65 | 73 | 316L | |
| 2"1/2-1"1/2 | 1.65 | 1.65 | 79.4 | 316L | |
| 2"1/2-2" | 1.65 | 1.65 | 79.4 | 316L | |
| 3"-1"1/2 | 1.65 | 1.65 | 79.4 | 316L | |
| 3"-2" | 1.65 | 1.65 | 85.7 | 316L | |
| 3"-2"1/2 | 1.65 | 1.65 | 85.7 | 316L | |
| 4"-2" | 2.11 | 1.65 | 85.7 | 316L | |
| 4"-2"1/2 | 2.11 | 1.65 | 104.8 | 316L | |
| 4"-3" | 2.11 | 1.65 | 104.8 | 316L |
FERRULES CLAMP LONGUES à SOUDER ASME BPE
| DN | Ep. | A | B | L | Nature |
| 1/2" | 1.65 | 25 | 44.5 | 23.4 | 316L |
| 3/4" | 1.65 | 25 | 44.5 | 24.6 | 316L |
| 1" | 1.65 | 50.5 | 44.5 | 31.1 | 316L |
| 1"1/2 | 1.65 | 50.5 | 44.5 | 33.4 | 316L |
| 2" | 1.65 | 64 | 57.2 | 33.2 | 316L |
| 2"1/2 | 1.65 | 77.5 | 57.2 | 33.1 | 316L |
| 3" | 1.65 | 91 | 57.2 | 43 | 316L |
| 4" | 2.11 | 119 | 57.2 | 42.5 | 316L |
FERRULES CLAMP COURTES à SOUDER ASME BPE
| DN | Ep. | A | B | Nature |
| 1/2" | 1.65 | 25 | 12.7 | 316L |
| 3/4" | 1.65 | 25 | 12.7 | 316L |
| 1" | 1.65 | 50.5 | 12.7 | 316L |
| 1"1/2 | 1.65 | 50.5 | 12.7 | 316L |
| 2" | 1.65 | 64 | 12.7 | 316L |
| 2"1/2 | 1.65 | 77.5 | 12.7 | 316L |
| 3" | 1.65 | 91 | 12.7 | 316L |
| 4" | 2.11 | 119 | 15.9 | 316L |
BOUCHONS CLAMP ASME BPE
| DN | A | B | Nature |
| 1/2" | 24.9 | 4.7 | 316L |
| 3/4" | 24.9 | 4.7 | 316L |
| 1" | 50.4 | 6.4 | 316L |
| 1"1/2 | 50.4 | 6.4 | 316L |
| 2" | 63.9 | 6.4 | 316L |
| 2"1/2 | 77.4 | 6.4 | 316L |
| 3" | 90.9 | 6.4 | 316L |
| 4" | 119.1 | 7.9 | 316L |
COLLIERS CLAMP FORGES SIMPLE ARTICULATION ASME BPE
| DN | A | B | C | Poids (kg) | Nature |
| 1/2" | 56 | 36 | 28 | 0.128 | 304 |
| 3/4" | 56 | 36 | 28 | 0.128 | 304 |
| 1" | 92 | 61 | 54 | 0.282 | 304 |
| 1"1/2 | 92 | 61 | 54 | 0.282 | 304 |
| 2" | 105 | 74 | 67 | 0.314 | 304 |
| 2"1/2 | 120 | 87 | 81 | 0.356 | 304 |
| 3" | 134 | 102 | 94 | 0.423 | 304 |
| 4" | 163 | 130 | 122 | 0.489 | 304 |
JOINTS DE RACCORDS CLAMP EPDM ou VITON ou EPDM/PTFE ASME BPE
| DN | A | B | D | Nature | Nature | Nature |
| 1/2" | 25 | 4 | 9.5 | EPDM | FKM | EPDM/PTFE |
| 3/4" | 25 | 4 | 16 | EPDM | FKM | EPDM/PTFE |
| 1" | 50.5 | 6.35 | 22.2 | EPDM | FKM | EPDM/PTFE |
| 1"1/2 | 50.5 | 6.35 | 34.9 | EPDM | FKM | EPDM/PTFE |
| 2" | 64 | 6.35 | 47.5 | EPDM | FKM | EPDM/PTFE |
| 2"1/2 | 77.5 | 6.35 | 60.2 | EPDM | FKM | EPDM/PTFE |
| 3" | 91 | 6.35 | 73 | EPDM | FKM | EPDM/PTFE |
| 4" | 119 | 6.35 | 98.4 | EPDM | FKM | EPDM/PTFE |
